SVTU-11V WATER METER

SVTU - 11V battery water meters are designed to measure all the necessary parameters of water consumption. Depending on the version they can be used to account for the volume of water.
- Accuracy degree – class 1, 2 (depends on performance);
- Case material – stainless steel or steel 20;
- Connection – flange;
- DN – 20 mm – 400 mm;
- Powering – battery (3.6 V);
- Service life – not less than 12 years;
- Warranty – 4 years.

The device accounts, displays and saves temperature, volume and mass of water. Saving provides in archives (hourly, daily, monthly, yearly). Ultrasonic waves emit in the flow direction and against. Based on time difference volume of water flow calculates.

SVTU-11V has a range of features:

- Flow meter section made of stainless steel or steel 20;
- Flow sensors made of titan (excludes pollution and accuracy reducing);
- There is possibility to produce flow node and temperature sensors for flooded places;
- Various packets performance for flow sensors tie-in with pressure to 16 atm;
- Standard package includes flanges (or clumping nuts), paronite gasket, fixing. For DN to 40 mm – straight sections (after 40 mm – by request);
- Device can provide flow measurement few times per second for accuracy increasing;
- Maximum cable length from computer to SVTU-11V sensors – 30 m. Maximum cable length to PC – 50 m. It allows to put out the computer from heat point to other place for comfortable working;
- We supply devices for Ukraine utilities and abroad.
